Grow FT1 Kiosk with Android QuickSale Q3
- Portrait Touchscreen Display
- Available in either 15.6” (317) or 21.5” (319)
- Resolution 1920 x 1080
- Kiosk base with metal bracket for Q3
- External Printer
- Available in Black
Pricing available to members only.
Overview
Technical Specs
Overview
CHARGE Anywhere Kiosk Solution
- Portrait Touchscreen Display
- Available in either 15.6†(317) or 21.5†(319)
- Resolution 1920 x 1080
- Kiosk base with metal bracket for Q3
- External Printer
- Available in Black
Technical Specs
POS System Technical Specifications
| System | Motherboard Processor Memory (on board) Stoage (on board) | G17 MediaTek G700 (MT8390) 4GB LPDDR4 64GB eMMC |
| Expansion | Storage | 1 x microSD Card Slot |
| Display | Size and Resolution Touch Screen | POS316: 11.6″ 1920 x 1080 POS317: 15.6″ 1920 x 1080 POS319: 21.5″ 1920 x 1080 True-Flat PCAP multi-touch |
| I/O Ports | USB Type-A USB Type-C FeDP Serial Port LAN Cash Drawer DC Jack Power Button | 4 x USB2.0 1 x USB3.0 full-functioned (DP/PD 5V/2A, 12V/1A) 1 x RJ48 (Powered RS232) (default: 0V; control by factory: 5V, 12V) 1x RJ45 (Optional: PoE Module IEEE 802.3bt, up to 51W) 1 x RJ11 (12V) 1 x 2PIN 1 |
| Audio | Internal Speaker | 1 x 3W (Option) |
| Power | Power Adapter | 36W / 12V |
| Communication | WLAN + BT | WiFi 6 + BT5.2 (default) |
| Peripheral (option) | MSR Fingerprint Reader* 2D Scanner* RFID Reader* Light Bar* 2nd Display | 3-Track MSR (USB) Fingerprint Reader (USB) 2D Scanner (USB) RFID (USB) Light Bar Module (USB) 11.6″ 2nd Display * The peripherals of the fingerprint, scanner, RFID, and light bar are project specific. |
| Certificate | EMC & Safety | FCC Class A, CE Mark Class A, LVD |
| Environment | Operating Temperature Storage Temperature Humidity | 0°C ~ 35°C I {32°F ~ 95°F) -20°C ~ 60°C I {-4°F ~ 140°F) 20% ~ 85% RH non-condensing |
| Dimensions | W x H x D | POS316: 289 x 275 x 193 mm POS317: 372 x 294 x 237 mm POS319: 516 x 336 x 308 mm |
| Mounting | VESA Mount | 75 x 75 mm |
| OS Supported | Android 13.0 (GMS) |
